Mesh Range
|
|
2-20 Mesh
|
6-30 Mesh
|
20-60 Mesh
|
|
Wire Diameter Range
|
|
1.22 to 0.50mm
|
0.55 to 0.27mm
|
0.45 to 0.071mm
|
|
|
|
(18 to 24 SWG)
|
(24 to 32 SWG)
|
(26 to 45 SWG)
|
|
Max Weaving width
|
|
1200 mm
|
1200 mm
|
1200 mm
|
|
|
|
(48 Inch)
|
(48 Inch)
|
(48 Inch)
|
|
Speed (Picks/Min.)
|
|
50
|
70
|
80
|
|
Wire Material
|
|
Gal. Iron, plain Iron, stainless steel, Brass, Copper, Silver, Aluminum
|
|
Type of Weave
|
|
Plain Weave
|
Plain Weave
|
Plain Weave
|
|
Motor Rating
|
|
3.7 KW (5 H.P.)
|
2.2 KW (3 H.P.)
|
2.2 KW (3 H.P.)
|
|
Floor Space Required
|
|
3200 mm X 2210 mm (L X W)
|
3200 mm X 2210 mm (L X W)
|
2925 mm X 2325 mm (L X W)
|
|
Auxiliary Machines:
|
Spares Required :-
|
|
Bobbin Winding Machine
|
Metal Reeds - FiberWooden Bobbins - Pickers-Heddles
|
|
Beaming-Up Machine
|
Hangers - Rubber Roller - Leather Belt for Shuttle Box
|
|
Bobbin Stand
|
Springs of different size.
|
|
Transfer Trolly
|
|
|
Wire Cloth Winding Machine
|
|
